OTOFIX IM2 Highlights:

1. No IP Restriction: this OTOFIX IM2 key programmer for all cars can be used in all countries on earth.
2. 2 Years Free Software Update: get the latest software updates for 2 years, without having to pay for pricey renewals.
3. Complete IMMO Coverage: support immobilizer functions on 80+ vehicle makes and models worldwide; 90% models for key programming via OBD.
4. Smart Mode & Expert Mode: for guided/automated key learning, or advanced key learning with quick access to desired functions. Confidently work with any OEM and aftermarket keys and fobs.
5. Advanced Key Programmer: PIN/CS access (all key lost), key generation, key learning, remote learning & activation; all is made easy.
6. Advanced IMMO: IMMO ECU reset/adaptation; IMMO ECU refresh/coding; IMMO restore; IMMO ECU data back-up with 64GB memory; all are easily accessible.
XP1 Pro Chips Programmer: Read/write transponder data, ECU/MCU/EEPROM data (e.g. 9S12 encryption chip), IC card, detect remote frequency; if you require chip read write or encryption capabilities.
7. Enhanced Operations: can run key learning and adaption for BM.W FEM/BDC; generate IR keys for Benz; add key for VW/Audi III/IV/V AKL; make transponder alterations for VWs and Audi MQB; read PIN/CS for Audi Q5/A4/A5 2015-2017; and many more. (See details on page)
8. Built-in Database Guidance: provide chip number, key frequency, key type, and maximum number of keys supported by the vehicle, while key programming on an unfamiliar vehicle.
9. Expand features with Key Programming Adapter G-Box2, and the Smart Key Emulator APB112 (Optional).
10. An OE-Level Diagnostic Scanner to Fix Most Car Repairs

ECU Programming: allows you to refresh ECU and upgrade OE-software.
ECU Coding: performs adaptations, matching, and personalization.
40+ Service Functions: cover all basic, special, and advanced functions that handle 99% of daily car maintenance.
Exceptional OE-level System coverage for all electronic systems
OTOFIX IM2 Description
Work with APB112 Key Simulator: the Smart Key Emulator (sold separately)

You can expand the OTOFIX IM2 features by connecting the XP1 Pro with APB112, a smart key emulator designed to collect information that is transmitted by the ignition coil. With this accessory unit, you can:
Identify any potential issues with the ignition coil.
Decode the data of the vehicle's key chip.
Emulate the vehicle key chip. It supports 46, 4D Data Collection, 46 Smart Key Password Calculation, 46 Chip Emulation, Toyota4D (94/D4, 98) Smart Key Emulation, Toyota H (88/A8, A9, 30) Smart Key Emulation, and more.

Work with G-Box3 Adpater: Key Programming Adapter for Benz & for BMW (sold separately)

You can also use OTOFIX IM2 working with the G-BOX3 to:

For Benz:
-Aide in the programming keys for DAS3 CAN EIS/EXS even if all keys lost.

-Get 4X/8X faster password calculations even if all keys lost. Have greatly simplified operation steps on W216 and W164 EISs after 2009, no more repeated insertions and removals of IR Simulator; available both in Boot/Bench method.

For BMW: Have DME/DDE ISN reading and writing in Boot/Bench Mode on applicable BM.W vehicles. The G-Box2 package contains all connections including cables, fuse connectors, and CAN Line connectors

OTOFIX IM2 Advantages:

1. The OTOFIX IM2 has been specially designed as a one-station key programmer immobilizer to help automotive locksmiths/mechanics/technicians to analyze, diagnose, and repair vehicles’ IMMO systems faster, and is being updated continuously as vehicles evolve. The specialized IMMO services are as follows:
IMMO ECU Reset (Adaptation)/Refresh (Coding): clear original IMMO data, and activate the new IMMO part replacement making sure all IMMO-related components are functional.
2. MMO Data Backup/Restore: back up the immobilizer data such as the vehicle's key programming and security settings, and restore it quickly in case of a system failure or when you need an IMMO component replacement.
3. PIN/CS Access (All Key Lost): read the PIN/CS code even if losing all original keys for making a brand-new available key; alter immobilizer data with retrieved PIN/CS code.
Add Key/Key Learning/Key Generation: retrieve the immobilizer data; add a new blade / smart car key replacement to suit the current settings of the vehicle.
4. Key Deletion: delete the unneeded key to prevent the car from being stolen if necessary.
Remote Control Learning: generate car remote replacements if losing the original remote.
5. 2 Operating Methods: Smart Mode & Expert Mode

OTOFIX has designed this advanced key programming scan tool with 2 unique operating modes to suit all experience levels and maintenance needs:
Smart Mode: walk you through key programming processes with on-screen instructions; is perfect for beginners and suitable to train new mechanics; Expert Mode: allow you to directly perform individual IMMO functions; is ideal for higher-experienced pros with more complex needs.
Superior Specification: Experience Seamless Navigation

Based on the U.S. most-popular operating system Android 10.0 for fast boot-up and multitasking.
Extraordinarily powerful Qualcomm SDM660 8-core processor. Ultra-crisp 10.1” LED touch screen (1920*1200) for optimum viewing.
Internal reliable 4GB RAM & 128GB on-board memory for storing more repair materials and better performance.
Built-in 16M rear camera with autofocus and flashlight, easy to capture repair parts and share them for extra help.

OTOFIX IM2 Functions:

ECU Programming: Full Control of ECUs

ECU programming is vitally important to your shop’s business, usually only seen on top-level diagnostic scanners. It could be the only way to:

Repair a specific issue that has been unforeseen when the vehicle was manufactured.
Program in a new blank ECU module so that everything works properly.
Get cost-effective OE upgrades without using expensive OE diagnostic tools.
The OTOFIX IM2 package includes a J2534-1&-2 pass-thru V1 Flash box, which allows you to access cloud-based online ECU programming for all-chassis BM*W and Ben-z cars. You just need to build a stable internet connection, follow the on-screen instructions, select the appropriate e-xecution options, and enter the correct data. If you have the OE-authorized programming software, you can also get factory-level power to obtain OE engine*ring corrections for additional car brands, such as Toyo-ta, Honda, Volvo, V-W, G-M, Chrysler, Jaguar, and Land Rover, among others.

Online & Offline ECU Coding: Win More Shop Orders

Compared to most other aftermarket scan tools, OTOFIX IM2 has a more advanced ECU coding feature. It can solve the following various issues:

Identify and configure a new CPU to match your vehicle's current settings.
Generate adaptive data for specific components after repairs have been done, helping to resolve significant car issues.
Personalize your car to your personal tastes (personalization), for example: recode your lighting setting, which includes changing the brightness levels or even the indicator flashing intervals; set optical or acoustic signals on the vehicle and different warning signals, such as a seat belt reminder. In addition, close some functions that you probably won't need like the auto star-t & sto-p system.
And you can get the work well done regardless of the level of skills thanks to its Online & Offline options:

With Online Coding, the OTOFIX servers calculate and send coding values automatically, offering you a fast and automated coding process. However, this feature is not compatible with Ben-z models.
With Offline Coding, you can manually input coding values and make more customized car settings.

WARM TIPS >> It's important to note that different car models have different software and modules, so specific coding features will vary accordingly.

40+ Service Functions
This versatile OTOFIX scanner gets nearly all initial adaptations, relearns, and resets in one station, to help you effectively restore car status after repairs are done. The 40+ service functions include the typical common maintenance service like Oil Reset/ SAS/ EPB/ BMS/ DP-F/ Throttle/ ABS resets. Meanwhile, it covers almost all major car brands, so you won't have compatibility issues.

OE-Level All System Scan
This all-system scan tool will open a whole window of system troubleshooting; get insight into what may trigger the problem in any parts: PCM/ECM/EPS/PDM/BCM/TPM/SCCM/RADIO/etc.; offer live stream, clear all DTCs in one touch to boost your effectiveness. AutoVIN & AutoSCAN (2006+) is very useful, to automatically find the matched VIN data and diagnostic procedure without manual operation.

Bi-Directional Control
This OTOFIX key programmer is also a full-bidirectional scan tool. That means you can send the command to the ECU and receive a response without the vehicle’s control. You can use it to drive the actuators to perform a specific function such as switching a solenoid, relay, or switch, between two operating states, so quickly spot the problem. Note that the available test varies by vehicle manufacturer, year, and model.

More High-end Functions
The smart Guided Function will lead you to go proper operations while running IMMO Service & Key Programming (doesn’t work on Benz/BMW/ LandRover). The cloud-based Report Management allows you to check test results anytime, anywhere. The advanced Scan VIN/License will detect the VIN automatically and pull the correct car information for you to smoothly run system diagnostics.

OTOFIX IM2 Vehicle Coverage:

This car key programmer has OE-level automotive diagnostic functions covering 80+ US, Asian and European makes, and 95% of [2014 - ] models, with OBD key programming covering 90% of the modern models worldwide.

WARM TIPS >> Go to the OTOFIX official site to check the vehicle compatibility, or reach us anytime for support.

For BMW: Read ISN from MD/MG Engine control units on bench // Key Matching for EWS immobilizer system …
For Benz: Support immobilizer service for Smart // access the 26 types of security code used in a car's immobilizer system // read, erase, or write in the immobilizer data of 3 types of transmission, 16 types of engine, the transmission control module (TCM), and the steering lock // Support Benz All Chassis Selection menu to match the proper immobilizer service operation …
For Ford: Cover 72 car models made in 1995-2021 // Support Keypad code // Access passive anti-theft system (PATS) or SecuriLock access // Scan & analyze the status of the car's immobilizer system // Reset the parameters and anti-theft information of IMMO systems …
For Chrysler: Cover 36 Chrysler models, 58 Dodge models, 25 Jeep models // Support Anti-theft service without PIN …
For VW/ Audi: Support 3rd, 4th, 5th gen. IMMO system service // Read PIN of BCM2 // Add Key (all keys lost) // Synchronize anti-theft data between the immobilizer system and the engine control module (ECM) for MQB, 5th gen. engine, transmission, and steering column lock component …
For PSA/ Peugeot/ Citroen: 10% more car coverage than competitors for Key Matching // 50% more PIN coverage than competitors for Read PIN via OBD // Clone BSI …
For Renault: Cover 67 models up to 2022 // Add Key without PIN for CLIOV/CAPTURII // Access passive anti-theft system (PATS) or SecuriLock access // Scan & analyze the status of the car's immobilizer system // Reset the parameters and anti-theft information of IMMO systems …
For Honda/ Acura: Cover 85 Honda models, 13 Acura models // Step-by-step instructions for replacing the specific IMMO component // Scan & analyze the status of the car's immobilizer system // Support VIN Code Auto Detect to provide the necessary information and procedures for IMMO services // Access immobilizer information of the vehicle …
For Nissan: Cover 9 makes, 504 models // Scan & analyze the status of the car's immobilizer system // Support VIN Code Auto Detect to provide the necessary information and procedures for IMMO services // Juke 22 to 20 Pin Code: program new keys for Nissan Juke models without having to manually convert the 22-pin connector to a 20-pin connector // 6+4 to 4 Pin Code: program new keys for certain Nissan models without having to manually convert the 6+4 pin connector to a 4-pin connector. // Key generation for T33, B18 (2022) without PIN // Smart Key generation (all keys lost) for D60/D60EV/T60 models …
For Hyundai/ Kia: Cover 4 makes, 365 models up to 2022 // Scan & analyze the status of the car's immobilizer system // Support VIN Code Auto Detect to provide the necessary information and procedures for IMMO services // Smart Key PIN Access for 47/4A/8A models // Access PIN for KX Cross // Anti-theft service and other basic IMMO functions …
For Fiat: Cover 8 makes, 181 models made in 1996-2023 // Support VIN Code Auto Detect to provide the necessary information and procedures for IMMO services …; For Toyota/Lexus: Cover 5 makes, 340 Toyota models, 233 Lexus models // Skip PIN for 4A, 8A-A8, A9, AA engines.
For GE: Cover 9 makes, 192 models made in 1993-2022 …; For Volvo: Cover 27 models up to 2021 …

OTOFIX IM2 Specification:

Operating system: Android 10.0
Memory: DDR+Storage 4GB+128GB
Screen: 10.1 inches
Resolution: 1920*1200
Connectivity: BT/USB
Battery: 15000mAh
VCI: V1 Flash
Camera: 16 Megapixel
Working Temperature: 0 to 50℃(32 to 122℉)
Storage Temperature: -10 to 60℃(14 to 140℉)

OTOFIX IM2 Package list:

1pc x OTOFIX IM2 Diagnostic Tool
1pc x OTOFIX V1 Flash
1pc x XP1 PRO
1pc x Main Cable
1pc x USB Cable (2m)
1pc x Mini USB Cable
1pc x AC / DC Adapter (12V)
2pcs x Spare Fuse (6*30mm)
1pc x Auxiliary Power Outlet Adapter
1pc x USB to Ethernet Adapter
1pc x APC101 (USB Cable)
1pc x APB104 (MCU_FQFP64)
1pc x APB105 (MCU_FQFP80)
1pc x APB106 (MCU_FQFP112)
1pc x APB107 (MCU_FQFP144)
1pc x APB108 (MCU_FQFP176)
1pc x APB109 (EEPROM Adapter)
1pc x APB125 (Mercedes-Benz Infrared Collection)
1pc x APA002 (EEPROM Socket)
1pc x APA101 (Singal Cable)
1pc x APA103 (EEPROM Clamp)
1pc x APA107 (ECU Cable)
1pc x APA108 (MCU Cable)
1pc x APA109 (MC9S12 Cable)
1pc x Connect Cable
1pc x Quick Reference Guide
1pc x Packing List
1pc x Carrying Case
